Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper

الصين Hentec Industry Co.,Ltd الشهادات
الصين Hentec Industry Co.,Ltd الشهادات
شكرا جزيلا لدعمكم لأكثر من 8 سنوات، ونحن نقدر حقا لنوعية جيدة من المنتجات وجودة الخدمة.

—— جيمس سكوت

تلقينا البضائع، أنها تبدو مثالية، شكرا لمساعدة فريق هنتك.

—— أني أونامونو

Le succès de ce nouveau projet dépend du support de l'équipe HENTEC en termes de technologie de traitement. Merci à HENTEC de nous aider à contrôler les coûts de manière efficace et à répondre à nos exigences en termes de haute qualité. Nous nous réjouissons de notre future cooperation!

—— يان باولز

ابن دردش الآن

Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper

Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper

صورة كبيرة :  Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper

تفاصيل المنتج:
إصدار الشهادات: SONCAP, ISO, RoHS, TUV
الوثيقة: كتيب المنتج PDF
شروط الدفع والشحن:
الحد الأدنى لكمية: 500
الأسعار: 2
مفصلة وصف المنتج
Alloy: 6063, 6061, 6005, 6060, 6082 Temper: T5, T6, T66
Surface Treatment: Anodizing, Powder coated, Brushed شكل: مربع
لون: فضي ، أسود قوة الشد: ≥ 160mpa (T5) ، ≥ 205mpa (T6)
قوة العائد: ≥ 110mpa (T5) ، ≥ 180mpa (T6) استطالة: ≥ 8%
أقصى قطر: 350mm القدرة الإنتاجية: 50000 قطعة / الشهر
نوع البولندية: البولندي الكيميائي / الميكانيكي Si Content: 0.2-0.6% (6063)
Mg Content: 0.45-0.9% (6063) Fe Content: 0.35% (6063)
Cu Content: 0.1% (6063)
إبراز:

6063 T5 Aluminum Cylinder,6000 Series Electrical Motor Shell,T3-T8 Aluminum Extrusion Profile

,

6000 Series Electrical Motor Shell

,

T3-T8 Aluminum Extrusion Profile

Anodized Electrophoresis Anti Scratch 6063 T5 Aluminum Cylinder / Electrical Motor Shell
Electric motor housing aluminum extrusion, also known as aluminum alloy motor shell or servo motor housing aluminum profiles, designed for industrial applications.
Product Features
  1. Material: Aluminum Alloy Extrusion Anodized Aluminium Profile for Pneumatic Cylinder
  2. Alloy temper options: 6063, 6061, 6005, 6060, 6082, T5, T6, T66
  3. Manufacturing standards: EN755, ASTMB221, DIN Standard
  4. Surface treatment options: Mill finish, Anodizing, Powder coated, Brushed
  5. Applications: Industrial equipment, Construction components
  6. Key advantages:
    • Pure 99.7% aluminum materials without scrap content
    • OEM services including custom die design and manufacturing
    • Customizable surface treatments to meet specific requirements
    • Strict quality control processes ensure superior quality
    • Hard alloy composition extends product lifespan
    • Safe and convenient packaging solutions
Manufacturing Process
Die design → Die making → Extruding → Cutting → CNC Machining → Surface treatment → Packing
Technical Specifications
Chemical Composition:
Alloy Si Fe Cu Mn Mg Cr Zn Ti Impurity Al
6063 0.2-0.6 0.35 0.1 0.1 0.45-0.9 0.1 0.1 0.1 0.15 Rest
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15 0.15 Rest
6060 0.3-0.6 0.1-0.3 0.1 0.1 0.35-0.6 - 0.15 0.1 0.15 Rest
6005 0.6-0.9 0.35 0.1 0.1 0.40-0.6 0.1 0.1 0.1 0.15 Rest
Mechanical Properties:
Alloy Temper Tensile strength Yield strength Elongation
6063 T5 ≥ 160Mpa ≥ 110Mpa ≥ 8%
6063 T6 ≥ 205Mpa ≥ 180Mpa ≥ 8%
6061 T6 ≥ 265Mpa ≥ 245Mpa ≥ 8%
Technical Support
Our comprehensive support includes:
  • Custom design services including CAD drawings and 3D models
  • Professional R&D team for design analysis and optimization
  • Complete "one-stop" production from design to surface treatment
  • Strict quality control throughout manufacturing process
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 0
Manufacturing Capabilities
Extrusion: 44 aluminum extrusion lines with maximum outer diameter capacity of 350mm, including a 6800 ton extruder for profiles up to 600mm diameter.
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 1
Anodizing: 6 production lines producing uniform oxidation films in various colors including silver, black, gold, champagne, and imitation steel.
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 2 Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 3
Painting: 4 powder spraying lines using Gema Switzerland nozzles with environmentally friendly, durable paints.
CNC Machining: Advanced equipment including 12 PRATIC machining centers, Wegoma cutting machines, 30 punching machines (50-100 ton), and 10 stretch bending machines.
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 4 Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 5 Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 6
Packing and Shipping
Finished products are manually packaged with strict warehouse management procedures ensuring quality control before delivery.
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 7
Certifications
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 8
Company History
2004: Recognized Brand of the Building Industry Material Market
2006: Certificate for Product Exemption from Quality Surveillance Inspection & ISO9001
2009: Advanced Company, Jiangsu Famous Brand Certificate, Credible Product of Quality in Jiangsu Province
2012: Established business relationships with Panasonic and LG
2015: Became innovative producer and supplying partner for BOSCH (Germany)
2017: Developed new baseboard heater products
2019: Cooperated with world's largest heater manufacturers
2023: Expanding overseas distributor network
Notable Projects
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 9
Soccer City Stadium, Johannesburg: Supplied aluminum components for Africa's largest 94,000-seat stadium.
Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 10 Anodized 6063 T5 Aluminum Cylinder Electrical Motor Shell with 6000 Series Alloy and T3-T8 Temper 11
Other Projects: Collaboration with Nordic trailer manufacturer Lobster Trailers and supply of aluminum legs for school furniture projects.
